Form Factor

2U Rackmount

Dimensions (Dx Wx H)

L650 x W437.5 xH88(mm)

Motherboard

Intel C612

Processor

Dual Processors.

2*Intel Xeon E5-2683 V4

RAM

8*DDR4 32GB，Total capacity 256G

SSD

2*Intel 2.5" 960G（RAID1,OS Disk)

Network

2*Intel 10GbE，4*Intel 1GbE

Drive Bays

External 3.5"/ 2.5"：12

Internal 2.5"：2

Raid Card

LSI 9260-8I/9361-8I

Expansion Slots

7*Half-height expansion slots

Powersupply

2U600W Single/CRPS 550W Redundant Dual PSU, AC 100V-120V/200V-240V/50Hz-60Hz

Color

Front Panel Coated Black (Others customized)

Front Control

1x Power On/Off, 1x System Reset, 1 x Unit Identification (UID) button,2 x USB 2.0

Indicators

1x Power Status, 2x LAN Activity, 1x HDD Status,1x Fan Fail/System Over Heat LED

1 x Unit Identification (UID) LED

Hotswap Backplane

1)6GB Mini SAS 8087 SGPIO Hot-swap Backplanes (Default)

2)12GB Mini HD 8643 SGPIO Hot-swap Backplanes (Option)

3)12GB Mini HD 8643 SGPIO Expand Hot-swap Backplanes (Option)

Cooling Fans

Default 3x 120mm(T=38mm), PWM Cooling fans

3*120mm fan bays（Middle）

Operating System

Centos 7/Ubuntu 20.04/Other etc.

Package Information

Dual Cartons+EPE

Application

Worker P1-P2, Link Server,Deep learning, AI, edge computing, etc
