| Dimensions (W x D x H) |
| • mm : 434 x 853 x 176 • inches : 17.1 x 33.5 x 6.9 |
| Industry Standard |
| EIA-RS310D |
| Material |
| Heavy-duty preplated SPGC cold-rolled steel |
| Color |
| Front Panel : Black |
| Cooling |
| Standard : • Middle : 4 x 80x38mm hot-swap fans • Optional : up to 2 x 60x38mm easy-swap fans |
| Power Supply |
| Option(s) : • 800W 2+2 redundant • 1200W 1+1 redundant |
| Expansion Slots |
| 7 full height |
| Front Panel |
| System power on/off, System reset |
| LED Indicators |
| Power, ID, Drive |
| System Board |
| 12”(W) x 13”(D) E-ATX/SSI EEB 3.6 compliant MB |
| Drive Bays |
| External : 2/4/6/8 x 2.5” hot-swap Internal : 60 x 3.5” hot-swap |
| Backplanes |
| • 2 x 30-port 12G SAS backplanes with 40-PHY expander • 2 x 30-port 24G SAS backplanes with 40-PHY expander (TBD) |
| Storage Temperature |
| 0ºC(32ºF) ~ 50ºC(122ºF) |
| Humidity |
| 5%~95% non-condensing |
| Gross Weight (w/ PSU & Rail) (excluding pallet) |
| • kgs : 45 • lbs : 99.2 |
| Package Dimension (W x D x H) |
| • mm : 586 x 1110 x 400 • inches : 23 x 43.7 x 15.7 |
| Cubic Feet |
| 9.25 |
| Container Load Quantity |
| • 20’ : 100 • 40’ : 212 • 40’ H : 255 |
| Mounting |
| Standard : 37” tool-less slide rail Option : Cable Management Kit |
* All specifications are subject to change without notice.
| Specification | |
|---|---|
| Industry Standard | EIA-RS310D |
| M/B Form Factor | ATX (12" x 9.6") |
| Drive Bay | • External: slim ODD x 1, hot-swap 2.5" x 2 • Internal: 3.5" HDD x 1 |
| Power Supply | Supports: • Form factor: Flex • Watt: up to 315W |
| Indicator | Power status, HDD, LAN activity LEDs |
| Front Control Panel | Power switch, system reset, USB 2.0 x 2 |
| tem | Part Number | Description | Support | Picture |
|---|---|---|---|---|
| Slide Rail | 3RAMIS032202 | 20" friction slide rails | 1 set |
|
| Cable | 3RAMW4024400 | SATA 7-pin to SATA 7-pin, 500mm | 2 |
|
| Power Supply | 1DDW265AU20015 | IP-S265AU7-2, 1U Flex, 265W, 80 Plus Bronze | 1 |
|
| Power Supply | 1DDU315AU20025 | IP-P315AU7-2, 1U Flex, 315W, 80 Plus Gold | 1 |
|
 |
